G6-Blue-Pro

Blue or Pro, EcoTech aims to bring you the absolute best of what’s technologically possible.

In the aquarium, enjoy richer colors, pop more fluorescence and create the ultimate balance between crisp and actinic.  From its inception, Radion has set the standard for what full spectrum aquarium LED lighting can be. The 6th generation pushes the limits of color rendition and fluorescence without sacrificing any of the famous flexibility that caters to the desire of the user.

With the addition of 395nm diodes, G6 pushes deeper into the UV range, achieving a new level of coral and fish fluorescence. Both Blue and Pro models also feature a rebalancing of color channels and LED (Diode) mix to augment the most flexible and balanced spectra available in aquarium lighting.

WIDE COLOR

Anatomy of the G6 Spectrum

395nm: Unlocks additional fluorescence in fish and corals.

400-450nm: Rebalancing the cluster with more blue and deep blue increases fluorescence, color rendition, and provides a new level of tunability in the blue spectrum between crisp and actinic.

460-580nm: Reduction in mid range spectral output maintains color expression in pigmentation while allowing for more wattage to be utilized in more photosynthetically useful and aesthetically valuable output.

665nm: Appropriate use of long wavelength diodes provide light output useful for coral photosynthesis as well as visual color balancing.

Radion Has it All

But how does it make your tank look?

Better than ever! The G6 Hybrid Hemispherically Edge Illuminating (HEI2) optic system combined with LED placement and form factor delivers beautiful shimmer, super color mixing, ridiculously even PAR, mind-blowing spread and even the ability to adjust the type of blue hue that you love the most.

What’s your preference, Professional Balance or Extreme Blue?
  • Mind-blowing Spread
  • Ultimate Fluorescence
  • Intense Full Spectrum Color
  • Fully programmable
  • Wireless Control
  • Moonlight
  • Weather Simulation
  • Technologically Superior Design
  • Premium Quality Components
  • Unmatched Support and Service
  • Extensive Mounting Options
  • Optional Diffuser Accessory

Mind-Blowing Spread

HEI2 Optical System

Spread so wide it has to be seen to be believed.

Radion G6 increases output from an impressive 110.5 degrees in the G5 to a staggering 126.3 degrees.

This improvement was achievable through a change to the primary optic on the LEDs which then integrates with the geometry in the existing HEI (Hemispherically Edge Illuminating) secondary optic (lens).

HEI2 Optic
Hemispherical Edge Illumination

Radion is a winner in the cost vs. output equation. The HEI2 optical system delivers 126.3 degrees of output. The result, incredibly even PAR over almost 4ft of coverage area making it the highest average output Radion and perhaps the most efficient aquarium light ever made.

RADION

G6 Blue

For those who love Blue – we present G6 Blue!

Bluer in every way and then some. Adjustments to the diode mix offer new depths of color intensity. With so much Blue, G6 now creates the opportunity to tune the Blue look between actinic and crisp. The addition of 395nm to the LED cluster pushes fluorescence in fish and corals to the next level.

RADION

G6 Blue

For those who love Blue – we present G6 Blue!

Bluer in every way and then some. Adjustments to the diode mix offer new depths of color intensity. With so much Blue, G6 now creates the opportunity to tune the Blue look between actinic and crisp. The addition of 395nm to the LED cluster pushes fluorescence in fish and corals to the next level.

Radion®

XR15 G6 BLUE

Perfect for aquariums 24-30 inches wide and deep. Put all of your power into Blue.

Dimensions
Length 7in.(18cm)
Width 7in.(18cm)
Height 1.5in.(3.9cm)
Weight 3.5lbs.(1587g)
Power Specifications
Power Consumption 95W
Universal Input Range 100-240VAC, 50/60Hz
Peak Inrush Current 1.3A
LEDs
Colors
4
Cool White
16
Royal Blue
16
Blue
1
Red
2
395nm
1
405nm
2
415nm
6
430nm
2
Warm White

Radion®

XR30 G6 BLUE

Full spectrum with LED selection favoring blue channels. Put all of your power into Blue.

Dimensions
Length 11.8in.(30cm)
Width 7in.(18cm)
Height 1.5in.(3.9cm)
Weight 4.5lbs.(2041g)
Power Specifications
Power Consumption 215W
Universal Input Range 100-240VAC, 50/60Hz
Peak Inrush Current 4.0A
LEDs
Colors
8
Cool White
32
Royal Blue
32
Blue
2
Red
4
395nm
2
405nm
4
415nm
12
430nm
4
Warm White

RADION

G6 Pro

The Radion Pro is responsible for lighting public aquariums, aquaculture facilities and coral spawning laboratories worldwide. Despite this, our most important user is the discerning home aquarist. Unbeatable in balanced output the G6 PRO carries the tradition further with extra capability in the blue and UV spectrum and mind-blowing additional spread!

RADION

G6 Pro

The Radion Pro is responsible for lighting public aquariums, aquaculture facilities and coral spawning laboratories worldwide. Despite this, our most important user is the discerning home aquarist. Unbeatable in balanced output the G6 PRO carries the tradition further with extra capability in the blue and UV spectrum and mind-blowing additional spread!

Radion®

XR15 G6 PRO

Perfect for tanks 24-30 inches wide and deep. Comprehensive spectrum and performance.

Dimensions
Length 7in.(18cm)
Width 7in.(18cm)
Height 1.5in.(3.9cm)
Weight 3.5lbs.(1587g)
Power Specifications
Power Consumption 95W
Universal Input Range 100-240VAC, 50/60Hz
Peak Inrush Current 1.3A
LEDs
Colors
8
Cool White
16
Royal Blue
8
Blue
2
Red
3
Green
2
395nm
1
405nm
2
415nm
4
430nm
4
Warm White

Radion®

XR30 G6 PRO

The industry standard for high output. Comprehensive spectrum and performance.

Dimensions
Length 11.8in.(30cm)
Width 7in.(18cm)
Height 1.5in.(3.9cm)
Weight 4.5lbs.(2041g)
Power Specifications
Power Consumption 215W
Universal Input Range 100-240VAC, 50/60Hz
Peak Inrush Current 4.0A
LEDs
Colors
16
Cool White
32
Royal Blue
16
Blue
4
Red
6
Green
4
395nm
2
405nm
4
415nm
8
430nm
8
Warm White

Mounting

Single Arm RMS

These two specialized kits are designed for XR15 and XR30 model Radions. Each kit contains everything needed to mount a Radion light on almost any standard or rimless tank.

Each kit contains multiple sliding rails and a rotatable x-bracket, allowing you to easily position your Radion precisely where you need it.

Mounting

Multi-Light RMS

The Multi-Light RMS offers a customizable multi-light mount solution for Radion XR30 and Radion XR15 lights. The Multi-Light RMS system features:

  • Built-in cable management
  • Compatibility with rimmed, rimless and euro-braced tanks
  • Rigid yet lightweight construction
  • Anodized aluminum finish
  • Slide mounts for horizontal and rotational adjustment
  • Optimal mounting for Radions at approximately 7 inches (18 cm) above the edge of the tank

Widgets. Widgets. Widgets.

You’ve invested in your ecosystem with the smartest and most capable EcoTech® equipment. Now unlock the true potential of this system with nothing more than an app on your smart device.

LEARN MORE

Widgets. Widgets. Widgets.

You’ve invested in your ecosystem with the smartest and most capable EcoTech® equipment. Now unlock the true potential of this system with nothing more than an app on your smart device.

LEARN MORE

HIGH INTENSITY (NARROW ANGLE) LENS KIT

The Radion comes standard with HEI Wide Angle Optics designed to maximize coverage while delivering a balanced and well-blended spectrum. For users looking to maximize output intensity, the High Intensity (Narrow Angle) Lens Kit provides a significant increase in intensity (PAR) in exchange for a reduction in spread. The flexibility this accessory brings to the Radion can be particularly beneficial for users mounting lights further from the aquarium, are looking for more light penetration in the aquarium or are looking to improve efficiency when less spread is needed.

UPGRADE FROM G5

Radion G6 models are built on the same heat sink and driver platform as the equivalent Radion G5 modes (XR15 or XR30). Excitingly this allows for a same model (XR15 and XR30) upgrade path for G5 to G6. Included in the upgrade kit is the G6 cluster and HEI lens – which together combine to create the Hybrid Hemispherically Edge Illuminating (HEI2) lens system.

In case you’re wondering – yes you can turn a Blue into a Pro or vice versa.

Radion® Diffuser

Models available for XR15 and XR30 Radion® Lights

Radion® Diffuser

  • Engineered diffuser material for improved color mixing and caustics
  • Quick and easy installation
  • Magnetically attached lens for easy removal and cleaning
  • Minimal reduction in PAR output
  • Diffusers custom-designed to fit G5/G6 models only

HOW IT WORKS

The Radion® diffuser utilizes an engineered diffuser material with an optimized airspace, the result is enhanced color mixing and more uniform caustics. Working with the existing optics equipped on the Radion® fixtures, a diffuser offers a more pleasing light appearance with only a minimal reduction in PAR.

Radion® Diffuser

Models available for XR15 and XR30 Radion® Lights

FEATURES

  • Engineered diffuser material for improved color mixing and caustics
  • Quick and easy installation
  • Magnetically attached lens for easy removal and cleaning
  • Minimal reduction in PAR output
  • G5 Diffusers custom-designed to fit G5/G6 models only

HOW IT WORKS

The Radion® diffuser utilizes an engineered diffuser material with an optimized airspace, the result is enhanced color mixing and more uniform caustics. Working with the existing optics equipped on the Radion® fixtures, a diffuser offers a more pleasing light appearance with only a minimal reduction in PAR.

Radion® Freshwater

XR15 and XR30 G5 Radion® Freshwater Lights

Radion Freshwater output offers a combination of full spectrum white LEDs maximizing plant health and growth augmented with RGB channels to showcase the rich colors of foliage and fish.

Radion® Freshwater

XR15 and XR30 G5 Radion® Freshwater Lights

Radion®

XR15 G5 FW

Perfect for Freshwater aquariums 24-30 inches wide and deep.

Dimensions
Length 7in.(18cm)
Width 7in.(18cm)
Height 1.5in.(3.9cm)
Weight 3.5lbs.(1587g)
Power Specifications
Power Consumption 90W
Universal Input Range 100-240VAC, 50/60Hz
Peak Inrush Current 1.3A
LEDs
Colors
12
Warm White
24
Cool White
3
Photo Red
3
Green
2
Blue
2
Lime
1
Moonlight White
1
Moonlight Blue

Radion®

XR30 G5 FW

LED selection favoring a spectrum that maximizes plant health and growth.

Dimensions
Length 11.8in.(30cm)
Width 7in.(18cm)
Height 1.5in.(3.9cm)
Weight 4.5lbs.(2041g)
Power Specifications
Power Consumption 180W
Universal Input Range 100-240VAC, 50/60Hz
Peak Inrush Current 4.0A
LEDs
Colors
24
Warm White
48
Cool White
6
Photo Red
6
Green
4
Blue
4
Lime
1
Moonlight White
1 - Moonlight Blue
